FRAME
7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. kinematics, 148x12 mm thru axle, internal cable routing, post mount 203 mm
FORK
FOX 38 Float Factory 29, E-Bike, Grip 2, 110 x 15 mm, 44 mm rake
TRAVEL FORK
170 mm
SHOCK
FOX Van Performance Coil, 230/65 mm, hardware: 25,0 x 8mm
MOTOR
Bosch Performance CX Gen4, 85 Nm, 250 W
BATTERY WATT-HOURS
625 Wh
BATTERY AMPERE HOURS
16,7 Ah
DISPLAY
Bosch Purion
SHIFTER
Shimano Deore XT M8100, 12-speed
REAR DERAILLEUR
Shimano Deore XT M8100, 12-speed
SPROCKET
Shimano SLX M7100, 12-speed
CHAIN
Shimano SLX CN-M7100, 12-speed
CRANKSET
Samox EC40 ISIS
TRANSMISSION OF DRIVE
front: 34, rear: 10-51
BOTTOM BRACKET
Integrated in Drive Unit
HANDLEBAR
RaceFace Chester 35, aluminium, 780 mm, rise: 35 mm, backsweep: 8°
STEM
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSET
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
SADDLE
Proxim W350
SEATPOST
Post Moderne dropper post PM-171, 31.6 mm
BRAKES
Shimano XT M8120, 4 piston
BRAKE LEVER
Shimano XT M8120, 4 piston
BRAKE
Disc
RIMS
RaceFace AR30 Offset
REAR HUB
Novatec D162 Disc, 12x148 mm
FRONT HUB
Novatec D041, 15x110 mm
TIRES
Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622
REAR TIRE
Schwalbe Magic Mary, 2.6 Super Gravity Soft, 65-622
GEARS
12
BIKE WEIGHT INCL. BATTERY IN KG.
26,2
