FRAME
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. Gen2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 180 mm
FRAME MATERIAL
Aluminium
FORK
Rock Shox Revelation RC 29 Boost, DebonAir, 110x15 mm, 46 mm rake
TRAVEL FORK
150 mm
SHOCK
RockShox Deluxe Select, 210/55 mm, hardware: 25,0 x 8mm, custom tune
SHIFTER
SRAM SX Eagle, 12-speed
REAR DERAILLEUR
SRAM NX Eagle, 12-speed
SPROCKET
SRAM PG-1210 Eagle, 12-speed
CHAIN
SRAM SX Eagle, 12-speed
CRANKSET
SRAM NX Eagle
BOTTOM BRACKET
BSA
TRANSMISSION OF DRIVE
front: 32, rear: 11-50
HANDLEBAR
Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
STEM
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSET
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
SADDLE
fi'zi:k Taiga
SEATPOST
Post Moderne dropper post PM-171, 31.6 mm
BRAKES
SRAM DB8, 4-piston, hydraulic disc brake
BRAKE LEVER
SRAM DB8, 4-piston, hydraulic disc brake
BRAKE
Disc
RIMS
RODI TRYP30, 30-622
REAR HUB
Novatec D462SB, 12x148 mm
FRONT HUB
Novatec D041, 15x110 mm thru axle
TIRES
Maxxis Minion DHF, EXO, 63-622
REAR TIRE
Maxxis Minion DHR II, 2.4 3C EXO+, 60-622
GEARS
12
BIKE WEIGHT INCL. BATTERY IN KG.
16
